3/8" Glass Door Rail CRL Black Powder-Coated 35-3/4" No Lock

• 35-3/4" (908 mm) length for 3/8" (10 mm) glass
• Use monolithic tempered glass
• Patented Wedge-Lock® glass securing system (U.S., Canadian & European patents)
• Models to fit 3/8" to 3/4" (10 to 19 mm) glass
• Available in several stock architectural finishes — custom finishes available
• Available with and without locks
• Matching sidelite rails available

Our innovative glass entrance solution, the CRL Wedge-Lock® Door Rail System, is a high-strength glass door rail system engineered for secure, fast installation. The patented Wedge-Lock® Securing System applies bottom-up wedge pressure using two aluminum glass-retaining extrusions and a flat stainless steel bar tightened with socket head cap bolts. As the bar pulls down, angled extrusions ride an angled groove in the door rail to create compressive force against the glass—generating substantial holding force (more than 900 lbs. in the 9" corner rail and proportionally more in the full-length 35-3/4" rail).

NOTE: Actual product height: 4-1/16" (103 mm).

Key benefits and differentiators:

• Fastest installation time among door rail systems — experienced installers can prepare a door in under ten minutes
• Completely fabricated and ready-to-install with end caps preinstalled
• Adjustable Door Alignment System (top and bottom) allows ±1/8" (3.2 mm) adjustment without removing the door
• Low-profile adjustable slide permits non-standard pivot setbacks and fabrication for vertically out-of-square openings
• Single-component rigid housing resists shift and loss of adjustment over time (not two-piece)
• Internal components remain assembled during installation; no disassembly required
• Durable glass securing pads designed for longevity in extreme environments

After installation, remove the end cap to access three socket head cap bolts: the center bolt secures the slide; the two outer bolts adjust the slide ±1/8" (3.2 mm).

NOTE: All Wedge-Lock® Door Rails include the built-in jamb alignment block. Arms, pivots, closer arms, and keyed cylinders or thumbturns must be ordered separately to meet job requirements.

Available finishes include several standard architectural options and custom finishes/widths by quote. Rail specifications, templates, and hardware packages are available from CRL Technical Sales via e-mail.

Ordering information:

• All door rails supplied with standard Kwik-Adjust™ pivot alignment system; floor or overhead pivots and closer arms sold separately
• Models with locks supplied with lock mechanism installed; matching finish keyed cylinders or thumbturns ordered separately
