CRL 22" Spiral Tilt Window Balance Replacement Red Bushing

• Red bushing indicates sash load up to 25 pounds (11.3 kg)
• Tilt window spiral balance for industry-standard 3/8" (10 mm) tube diameter
• Direct replacement for metal or plastic tube balances

CRL Tubular Spiral Window Balance (SKU FL2220) — Designed for tilt-type windows, this tubular spiral balance replaces same-size metal or plastic tube balances and matches white-bushing spiral balances. Rated for sash loads up to 25 lb (11.3 kg). Sold individually; for optimal performance and balanced operation, we recommend replacing both balances in the window simultaneously.

How to Order Tubular Spiral Window Balances

1. Check the tube diameter on the old balance (3/8" / 10 mm is industry standard).
2. Measure the tube length from the end of the balance to the bottom of the colored nylon bushing only — do not include the rod extension.
3. Note the color of the nylon bushing (red indicates up to 25 lb for this model).
4. Verify the rod extension shape and length protruding from the nylon bushing matches your existing part.
5. Match tube diameter, tube length, and bushing color to the specifications shown next to the catalog number. If all match and the rod extension looks identical, this is the correct balance.

Need help confirming fit for your tilt window spiral balance? Contact our support team or add SKU FL2220 to your cart to get started.
