- Fits 1/2" to 5/8" (12 to 16 mm) monolithic tempered glass
- Pre-drilled in 10' and 20' lengths (SKU: B5L20D6)
- Low-profile design for residential and yacht glass railing applications
- Used as the base channel for glass railing systems and windscreens
- Custom cutting and mitering service available
The
CRL B5L Series Custom Low Profile Square Aluminum Base Shoe is a low profile aluminum base shoe engineered as the base channel for wet-glaze glass railing systems. Designed for easy attachment to substrate, the extrusion accepts several architectural cladding finishes (recommended: cladding over base shoe rather than direct powder coating). CRL provides tested drilling patterns and fastener combinations to ensure secure installation of glass railing and windscreen systems.
GLASS SPECIFICATIONS:
1/2" (12 mm) to 5/8" (16 mm) thick tempered glass when using the Wet Glaze System.
Note: Low Profile Square Base Shoe is not compatible with the TAPER-LOC® or wedge dry-glaze systems.
SHIPPING NOTE:
20' (6.1 m) stock lengths are difficult to package and handle; Will Call pickup at a CRL distribution center is suggested. If shipment is required, packaging and handling must be agreed upon with CRL before shipping and will be documented on your quotation.
Product Warning:
For use only with 1/2" or 5/8" (12 or 16 mm) glass in Wet Glaze systems. Do not use with Wedge Dry Glaze systems. CRL recommends applying powder-coated cladding over the base shoe rather than direct powder coating of the extrusion.
All pre-drilled CRL base shoes have a hole-spacing tolerance of +1/8" (3 mm) / -1/16" (1.5 mm). Before drilling substrate installation holes, place the base shoe in final position and mark hole locations on the substrate.
Shipping weights are approximate. Request exact weight from CRL Customer Service if needed to calculate shipping costs. Product images are representative; actual color may vary by monitor.
Optimize your glass railing project with the CRL B5L Series low profile aluminum base shoe — contact CRL Customer Service to order or request custom cutting.
