CRL
CRL
CRL 316 Stainless Steel 84" Polished Upward-Locking Ladder Pull
Item# LLPUA84PS
Shipping Weight: 17.857 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 17.857 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Buy More, Save More!
| Product QTY | Discount |
|---|---|
| Buy 3 | 2% Off |
| Buy 5 | 4% Off |
| Buy 10 | 6% Off |
| Buy 15 | 8% Off |
| Buy 20 | 10% Off |
Adaptor For 1 3/4 Inch Thick Doors
LLPA134ADT
Diameter
1-1/4 in. (32 mm)
Finish/Color
Polished Stainless Steel
Glazing Thickness
3/4 in. (19 mm)
Material
316 Stainless Steel
Mounting Points
3
Mounting Type
Back-to-Back
Overall Length
84 in. (2134 mm)
- Locks into the ceiling only — upward locking ladder pull for glass doors
- A.D.A. compatible thumbturn mounted at a comfortable 42" (1.07 m) above finished floor
- Adaptor kits available for 1-3/4" (45 mm) thick doors — LLPA134ADT
- Accepts 1/2" to 3/4" (12–19 mm) tempered glass
- 1-1/4" (32 mm) diameter alloy tubing available in 316 brushed or polished stainless steel
- Custom sizes ship within one to two weeks
- A.D.A. compliant models available — ask for a quote
Our CRL LLPUA Series Upward Locking Ladder Pulls (SKU: LLPUA84PS) feature a fully concealed deadbolt that locks into the ceiling — not the floor — eliminating the need to bend or reach to secure the door. The keyed cylinder and A.D.A. compatible thumbturn are positioned at a comfortable height for easy operation on commercial and architectural glass doors. Available finishes include brushed and polished 316 stainless steel for corrosion resistance and a premium look.
Supplied with a standard 7-pin rim cylinder with interchangeable core for easy rekeying or replacement. The pull accepts most standard rim-type cylinders; proprietary 6-pin cylinders may be installed by replacing the supplied rim cylinder. Push/pull indicators and dustproof keepers sold separately. Glass fabrication required.
Most shipping weights are approximate. If exact weight or shipping costs are required to complete your order, contact CRL Customer Service prior to submitting your order. Product images are representative; colors may vary by monitor.
Stainless Steel Advisory:
Stainless steel is corrosion-resistant but not impervious to staining. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in the Technical References for care guidelines.
Ready to specify a secure, ADA-friendly upward locking ladder pull for tempered glass doors? Contact CRL for a quote or to order SKU: LLPUA84PS.
CAD Drawings - dwg
