Product Details
- Available in Three Convenient Pre-Cut Lengths
- Satin Anodized, and Brushed Nickel Finishes
These Track Assemblies are smooth operating, and will provide years of reliable service. CRL's Low Profile Track Assembly, available in three popular pre-cut lengths, is the most efficient way to purchase a track system for your pass-thru since it minimizes waste of materials.
All the Track Assembly components you require are packed in a convenient shipping tube. They are easy-to-install. The two pieces of 'H' Bar for the bypassing doors have a 1-1/2" (38 mm) overlap. CRL Cat. No. D332 End Caps for the 'H' Bar can be purchased separately. For dry glazing with 1/4" (6 mm) glass use Cat. No. GC728C Vinyl sold separately). To provide security, refer to the large selection of CRL Ratchet and Plunger Type Locks are available.
NOTE: Maximum suggested panel size is 36" W x 48" H (914 mm x 1.22 m).
General Glass Cutting: Guidelines Glass Height = Opening Height Minus 1-1/8" (28.6 mm)
Components for D2203BN
D602 (x1)
D603 (x1)
D650 (x12)
D610 (x1)
D652 (x12)
D9650 (x1)
Product Warning:
If you need a very tight fit, you should figure your own dimensions. The dimensions shown are just guideline dimensions that are satisfactory to most installers.
D2203 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-1/8"
D2204 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-1/8"
D2300 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8"
D2301 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8"
D2303 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8"
D2305 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-3/8"
D2306 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-5/8"
D2307 Series = Rolling Track Assembly: Glass Height = Opening Minus 1-5/8"
