CRL 8B Aluminum Square Base Shoe 240" Pre-Drilled for 1/2" Glass
Item# 8B20D
Shipping Weight: 124.217 Pounds
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 124.217 Pounds
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Drilling Center To Center
12 in. (305 mm)
Finish/Color
Mill
Glazing Thickness
1/2 in. (13 mm)
Glazing Type
Monolithic
Height
4-1/8 in. (105 mm)
Length
240 in. (6096 mm)
Material
Aluminum
Width
2-1/2 in. (64 mm)
- 30% lighter than CRL's traditional B5S Series shoe — reduced weight for lower shipping costs
- Square base shoe designed and engineered for guard rail and windscreen applications
- For use with 1/2" (12 mm) monolithic tempered glass
- Available in 10' and 20' stock lengths — drilled and undrilled options
- Environmentally friendly aluminum alloy (green product)
- Easily cut to length using a chop saw with a minimum 10" (254 mm) blade for aluminum
- Compatible with CRL's patented TAPER-LOC® system
- CRL glass railing systems meet NBC load requirements when installed in accordance with ICC-3269
This CRL 8B Series Square Base Shoe (SKU 8B20D) shares the same profile as the standard B5S Series but is 30% lighter—making it a cost-effective, eco-friendly choice for aluminum glass railing and windscreens. Ideal for installers specifying an aluminum glass railing base shoe for 1/2" tempered glass; easily cut to size and compatible with TAPER-LOC® accessories.
Most shipping weights are approximate and have not been verified. If exact weight is required to determine shipping costs, please contact CRL Customer Service before placing your order. Product images are of the actual product or a close representation; colors may vary depending on monitor settings.
Order SKU 8B20D or contact CRL Customer Service to confirm availability and shipping details.
