CRL SSR Bottom-Rolling Sliding Door Hardware Kit - Black Bronze OXO

CRL SSR Bottom-Rolling Sliding Door Hardware Kit - Black Bronze OXO

$0.00 CAD
$0.00 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# SSR3EDU
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Door Configuration
OXO
Finish/Color
Black Bronze Anodized
Height
4 in. (102 mm)
Material
Aluminum
Maximum Door Height
108 in. (2743 mm)
Maximum Door Width
48 in. (1219 mm)
Minimum Door Width
234 in. (5944 mm)

Overview

  • With 4" Tapered DR4T Series Door Rails and 4" Tapered SR4T Series Sidelite Bottom Rails
  • Available in Seven Architectural Finishes

The CRL SSR Bottom Rolling Sliding Door System (SKU: SSR3EDU) is a bottom-rolling sliding door system with 4" (102 mm) tapered rails designed for commercial and architectural applications. It features the proven Wedge-Lock® Glass Securing System used in our DR4T Series Door Rails on all sliding panels and is available with or without locks in the bottom rail for enhanced security and smooth operation.


Fixed sidelites use the SR4T Series Sidelite Rails with roll-in vinyl at the bottom and an integrated glazing channel with roll-in vinyl in the top track. Maximum door width: 48" (1.22 m); maximum door height: 108" (2.74 m); maximum panel weight: 234 lb (106 kg). All panels are custom fabricated to your specifications and offered in seven architectural finishes—ideal for commercial storefronts, offices, and ADA-compliant openings.
