CRL SSR Black Powder-Coat Bottom-Rolling Sliding Door System XO/OX

CRL SSR Black Powder-Coat Bottom-Rolling Sliding Door System XO/OX

$0.00 CAD
$0.00 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# SSR2CBL
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Door Configuration
XO/OX
Finish/Color
Black
Height
4 in. (102 mm)
Material
Aluminum
Maximum Door Height
108 in. (2743 mm)
Maximum Door Width
48 in. (1219 mm)
Minimum Door Width
234 in. (5944 mm)

Overview

  • 4" Tapered DR4T Series Door Rails for sliding panels and 4" Tapered SR4T Series Sidelite Bottom Rails
  • Available in seven architectural finishes

CRL SSR Bottom Rolling Sliding Door System (SKU: SSR2CBL) — a heavy-duty bottom rolling sliding door system featuring 4" (102 mm) tapered rails and the proven Wedge-Lock® Glass Securing System used in DR4T Series door rails. Sliding panels can be specified with or without locks in the bottom rail for secure, customizable operation.


Fixed sidelites use SR4T Series rails with roll-in vinyl at the bottom and an integrated glazing channel with roll-in vinyl in the top track. Maximum door width: 48" (1.22 m). Maximum door height: 108" (2.74 m). Maximum panel weight: 234 lb (106 kg). All panels are custom fabricated to your specifications.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs prior to ordering, please contact CRL Customer Service. Product images are representative; actual colors may vary with monitor settings.

Choose the CRL SSR bottom rolling sliding door system for durable, low-profile bottom-rolling performance and versatile architectural finish options — contact CRL to get a custom quote today.
