• CRL SDR bottom-rolling sliding door system (SKU 4SDR42FBL), gloss black 4" square rails for heavy frameless glass panels.
1 1

CRL

CRL Black Powder-Coated XXXX Sliding Door Entry - 4 in Square Rail

CRL Black Powder-Coated XXXX Sliding Door Entry - 4 in Square Rail

Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 4SDR42FBL
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Gloss Black
Height
4 in. (102 mm)
Maximum Door Height
108 in. (2743 mm)
Maximum Door Width
48 in. (1219 mm)
Maximum Panel Weight
234 lbs. (106.1 kg)
Panel Count
4

Overview

  • With 4" Square DR4S Series Door Rails
  • Available in Seven Architectural Finishes

CRL SDR Bottom Rolling Sliding Door System (SKU: 4SDR42FBL) features 4" (102 mm) square top and bottom rails from the DR4S Series and uses the proven Wedge-Lock® Glass Securing System for secure, frameless glass panels. Rails are custom fabricated to your specifications for both door and fixed panels. Order doors with or without bottom-rail locks. Designed as a heavy-duty bottom rolling sliding glass door solution for commercial and high-end residential applications.

  • Maximum door width: 48" (1.22 m)
  • Maximum door height: 108" (2.74 m)
  • Maximum door weight: 234 lbs. (106 kg)

Available in seven architectural finishes to match storefronts, interior partitions, or custom glazing projects. Ideal long-tail keyword targets: "bottom rolling sliding door system with 4-inch square rails", "Wedge-Lock glass securing sliding door", and "custom DR4S sliding door rails".

Contact CRL Customer Service for custom configurations, finish options, or to confirm exact shipping weight before ordering.

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.
