CRL-Blumcraft Polished Stainless Left Door-Mount Keyed 'Z' Panic Handle

• For 1/2" or 3/4" (12 or 19 mm) tempered glass doors — ideal replacement for older panic devices
• Custom sizes ship within one to two weeks
• Optional keyed access and electric strike available
• Certification: ANSI/BHMA A156.3 - 2001 Grade 1

This CRL Glass Door Panic Handle is engineered for maximum view and a contemporary aesthetic on 1/2" or 3/4" (12 or 19 mm) tempered glass doors. Suitable for single or double doors, these panic handles are ready-to-install on 36" to 48" (914 mm to 1.22 m) wide doors with heights from 90" to 102" (2.29 to 2.59 m) without modification. "Dogging" (locking the device in the open position) is simple with a slide knob. A door stop/strike must be ordered separately; a threshold strike plate is available for the PA110 series. Custom header options are available with pre-installed hardware.

• Material: 1-1/4" (32 mm) diameter 385 bronze or 304 stainless steel tubing (2 mm thick)
• Glass Thickness: 1/2" or 3/4" (12 or 19 mm)
• Glass Fabrication: Varies — please contact CRL Technical Sales for details

When ordering panic handles you must specify:

• PA100 or PA110 Series (SKU example: PA100Z4AKPS)
• Exterior handle option (click here)
• Right or left hand (as viewed from the outside)
• Rail mount (for doors with full-length rails) or glass mount (for doors with patch rails)
• Standard retainer plate or optional keyed access device
• Finish: brushed or polished stainless, satin or polished brass
• Optional threshold strike plate (PA110 Series only)

Contact CRL Technical Sales for specification details and pricing for all-glass entrance doors.
