CRL-Blumcraft® Polished SS Right-Hand Reverse Rail Keyed Panic Handle
CRL-Blumcraft® Polished SS Right-Hand Reverse Rail Keyed Panic Handle
Regular price
$11,010.18 CAD
Regular price
Sale price
$11,010.18 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# PA100JS3RKPS
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov

Description
Application
DRS Rail Mount
Diameter
1-1/4 in. (32 mm)
Exterior Access
Yes
Finish/Color
Polished Stainless Steel
Glazing Thickness
1/2 in. (13 mm)
Handing
Right Hand Reverse
Keying
Cylinder Outside Only
Latching
Top
Material
Stainless Steel (Alloy 304)
Overview
- UL, ULC, and ANSI/BHMA certified
- Elegant tubular design
- Wide selection of exterior fixed handles for 1/2" (12 mm) or 3/4" (19 mm) tempered glass doors
- Available finishes: Polished Stainless, Brushed Stainless, Satin Brass, Polished Brass, Oil Rubbed Bronze
- Custom finishes available by special order
- Custom sizes ship within one to two weeks
CRL-Blumcraft® manufactures a complete line of access control handles and panic hardware specifically engineered for all-glass doors. Our product family includes panic devices, deadbolt handles, electronic egress control handles, and matching dummy handles to maintain a consistent appearance across a project while minimizing cost.
The PA100 Series panic handle (SKU: PA100JS3RKPS) is a popular, ADA-compliant panic solution for tempered glass storefronts and commercial entrances. Its concealed operating mechanism inside the vertical tubing retracts the latch when the interior actuation bar is pushed. An optional exterior keyed access device or electric strike provides secure, remote or keyed entry options. A built-in dogging feature locks the device in the open position for business hours, and custom headers can be supplied with strike hardware pre-installed.
Designed to maximize viewing area, the interior portion is a slender 1-1/4" (32 mm) tube that spans the door and turns upward to the top, keeping the lower glass area clear to meet A.D.A. clearance requirements. These panic handles are ideal long-tail search scenarios such as "ADA-compliant panic handle for tempered glass door" and "panic hardware for all-glass commercial doors."
For complete specifications and catalog pages, view the CRL-Blumcraft® Access Handle product details here.
Stainless Steel Advisory:
Stainless steel resists corrosion but is not rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for details.
Ready to order or need a custom finish? Contact CRL Technical Sales or Customer Service for a quote and lead time.
