CRL

CRL-Blumcraft® Brushed Stainless Keyed Panic Handle Right-Hand

CRL-Blumcraft® Brushed Stainless Keyed Panic Handle Right-Hand

Regular price $11,537.79 CAD
Regular price Sale price $11,537.79 CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Item# PA100FS3LKBS
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Application
Low Profile Rail Mount
Diameter
1-1/4 in. (32 mm)
Exterior Access
Yes
Finish/Color
Brushed Stainless Steel
Glazing Thickness
1/2 in. (13 mm)
Handing
Right Hand Reverse
Keying
Cylinder Outside Only
Latching
Top
Material
Stainless Steel (Alloy 304)

Overview

  • UL, ULC, and ANSI/BHMA Certified
  • Elegant tubular design for contemporary all‑glass entrances
  • Fits 1/2" (12 mm) or 3/4" (19 mm) tempered glass doors
  • Available finishes: Polished Stainless, Brushed Stainless, Satin Brass, Polished Brass, Oil Rubbed Bronze
  • Custom finishes available by special order
  • Custom sizes ship within one to two weeks

CRL‑Blumcraft® manufactures a complete line of access control handles for all‑glass doors, including panic devices, deadbolt handles, electronic egress controls, and matching dummy handles to maintain a uniform appearance while minimizing costs.

The PA100 Series (SKU: PA100FS3LKBS) is a popular ADA‑compliant panic handle option designed for maximum viewing area on 1/2" and 3/4" tempered glass doors. Its interior mechanism is concealed within a slender 1-1/4" (32 mm) vertical tube that spans the door and turns upward to clear the lower half of the door—helping meet Americans With Disabilities Act (A.D.A.) requirements.

Key functional features:
  • Interior actuation bar retracts the latch bolt when pushed
  • Optional exterior keyed access device for controlled entry
  • Dogging feature locks the device in the open position for business hours
  • Compatible with electric strikes for remote keyless entry
  • Custom headers available with strike hardware pre‑installed
For secured entry applications, electronic strikes and a variety of keyed and electronic configurations are available to suit commercial glass door installations.

Find complete specifications and catalog details on our product page here or contact CRL Technical Sales via the Contact Us page (select Technical Sales for Commercial Products).

Most shipping weights are approximate. If you need exact weights for shipping cost calculation, contact CRL Customer Service before placing your order. Product images are representative; actual colors may vary by monitor and video settings.

Stainless Steel Advisory:
Stainless steel resists corrosion but is not completely rust‑proof. Periodic maintenance is recommended to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for details.


Call or order online now to specify PA100FS3LKBS for your tempered glass door project.
