CRL
CRL-Blumcraft 3243 Satin Anodized 1-1/2" Sq Aluminum Cap Rail
CRL-Blumcraft 3243 Satin Anodized 1-1/2" Sq Aluminum Cap Rail
Regular price
$1,137.00 CAD
Regular price
Sale price
$1,137.00 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# 3243SA
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: Stock Length
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: Stock Length
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Satin Anodized
Glass Pocket Width
1 in. (25 mm)
Glazing Insert
ST302
Glazing Thickness
13/16 in. (21 mm)
Height
1-1/2 in. (38 mm)
Length
120 in. (3048 mm)
Material
6063-T5 Aluminum
Top of Rail to Top of Glass Pocket
3/8
Width
1-1/2 in. (38 mm)
Overview
- Intended for use on 3/4" (19 mm) tempered glass
- Ready-to-install extruded heavy-duty solid aluminum construction (6063-T5)
- Available in two architectural finishes; mill aluminum available from stock
- Stainless steel adapter strips sold separately; adapter strips must be installed with Very High Bond cladding tape before fitting the cap rail
- Sold in 120" (3.05 m) stock lengths or custom fabricated to size
- Pre-drilled holes 24" (610 mm) on center and set screws along one side for attachment to adapter strips
CRL-Blumcraft® 3243 Series Cap Rails (SKU 3243SA) are extruded from 6063-T5 aluminum for durable, architectural-grade aluminum cap rails designed for 3/4" tempered glass applications. These aluminum cap rails provide a clean finished edge for glass railings and balustrades and are available in two architectural finishes or mill aluminum from stock. For proper installation and long-term performance, stainless steel adapter strips, Very High Bond cladding tape, and splice pins are required (adapter strips sold separately).
Installation notes: Install the stainless steel adapter strips to the glass edge with Very High Bond tape before sliding on the cap rail. Each cap rail ships with pre-drilled holes at 24" (610 mm) on center and set screws for secure attachment to the adapter strips.
Order CRL-Blumcraft® 3243SA cap rails for tempered glass railings—contact CRL Customer Service to request custom fabrication or shipping-weight details.
Specifications
Brochures & Literature
