CRL Brite 12" Anodized Aluminum Mounting Bracket

• SKU: 122BA12
• Available in five finishes and five lengths: 4", 6", 8", 10", 12" (102, 152, 203, 254, 305 mm)
• Designed for CRL Series 22 and Series 322 aluminum standards

CRL Aluminum Brackets — concealed-slot aluminum shelf brackets available in five finishes and five sizes. These slip into hidden slots on our Series 22 and Series 322 aluminum standards and are secured by tapping the bracket down. These brackets have no back flange and are designed specifically for CRL aluminum standard systems.


Shelf Weight Capacities (based on two standards mounted 16" / 406 mm apart with screws into wall studs):
4" (102 mm) — 75 lbs (34 kg)
6" (152 mm) — 65 lbs (29 kg)
8" (203 mm) — 55 lbs (25 kg)
10" (254 mm) — 45 lbs (20 kg)
12" (305 mm) — 35 lbs (16 kg)


Product Warning:

These aluminum brackets are not interchangeable with steel standards or bracket systems from other manufacturers. Deduct 1/16" from the depth of a glass shelf when using these aluminum brackets.

Order SKU 122BA12 today to get durable, concealed-slot CRL aluminum shelf brackets for Series 22/322 standards.
