CRL Brushed Chrome Grade 2 Heavy-Duty Privacy Door Lever Lockset
Item# D35PRV
Shipping Weight: 3.71 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 3.71 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Buy More, Save More!
| Product QTY | Discount |
|---|---|
| Buy 3 | 2% Off |
| Buy 5 | 4% Off |
| Buy 10 | 6% Off |
| Buy 15 | 8% Off |
| Buy 20 | 10% Off |
Backset
2-3/4
Category
Door Accessories
Certification
ANSI A156.2 Grade 2
Door Thickness Range
1-3/8" To 1-3/4"
Door Type
Aluminum, Wood, Hollow Metal
Finish/Color
Brushed Chrome
Fire Rating Hour
3
Function
Privacy
Handing
Non Handed and Reversible
Handle Length
4-5/8
Includes
Strike
Operation Type
F76 Privacy Lever
Projection
2-1/2
Rosette Base Height
11/16
Rosette Base Width
3-3/8
Strike Height
4-7/8
Strike Width
1-1/4
Type
Standard Duty Lever Lockset
UL Listed
Yes
- ANSI A156.2 Grade 2
- UL Listed — 3-hour fire rating
- 3 Year Warranty
These CRL heavy-duty commercial lever locksets (SKU D35PRV) are non-handed, reversible privacy lever locksets designed for commercial and multi-family applications. UL Listed with a 3-hour fire rating, this fire-rated privacy lever fits standard door thicknesses from 1-3/8" to 1-3/4" (35 to 45 mm) and uses a 2-3/4" (70 mm) backset. An ANSI strike (1-1/4" x 4-7/8" / 32 x 124 mm) is included for quick installation.
PRIVACY FUNCTION DESCRIPTION: Pushbutton locking from inside; emergency access from outside with a narrow flat-head screwdriver or by rotating the inside lever — ideal for bathrooms, changing rooms, and private offices requiring a keyed-alike or emergency-access privacy solution.
Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and monitor settings.
Find the D35PRV privacy lever lockset for reliable, fire-rated commercial door hardware—order now or contact CRL for technical details and bulk pricing.
