CRL Brushed Nickel Small Glass Door Set-Screw Hinge 1/4–5/16 in
CRL Brushed Nickel Small Glass Door Set-Screw Hinge 1/4–5/16 in
Regular price
$56.65 CAD
Regular price
Sale price
$56.65 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# EH73
Shipping Weight: 8.0 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pack
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 8.0 Ounces
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pack
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Brushed Nickel
Glazing Thickness
1/4 in. To 5/16 in. (6mm To 8 mm)
Height
1 in. (25.4 mm)
Material
Brass
Maximum Door Width
16 in. (406.4 mm)
Pack Quantity
2
Weight Capacity
8 lbs. (3.6 kg)
Width
1-1/4 in. (31.8 mm)
Overview
- Available in several finishes
- For 1/4" to 5/16" (6 to 8 mm) glass
- No holes or cut-outs required — no-drill attachment
- Use with monolithic tempered glass
The CRL Hinge is a general-purpose glass-to-wall hinge designed for monolithic tempered glass. Glass is secured with plastic-tipped set screws for a no-drill installation—ideal when preserving glass integrity is critical. Maximum recommended door width: 16" (406 mm). Maximum weight: 8 lbs. (3.6 kg). Two hinges per pack with matching finish wood screws.
SKU: EH73
Shop now to get the no-drill glass-to-wall hinge for your tempered glass door.
Specifications
CAD Drawings - dwg
