CRL Brushed Stainless 6" Square Door Pull w/ Lock for 3/4" Glass - Custom Length

• Custom Length for 3/4" (19 mm) Glass
• Use Monolithic Tempered Glass
• Patented Wedge-Lock® Glass Securing System
• Models to Fit from 3/8" to 3/4" (10 to 19 mm) Glass
• Available in Several Stock Architectural Finishes - Custom Finishes Available
• Available With and Without Locks
• Matching Sidelite Rails Available

An innovative glass entrance solution, the CRL Wedge-Lock® Door Rail System (SKU: DR6SBS34CL) uses the exclusive CRL Wedge-Lock® Securing System (U.S. Patents 6,434,905 and 6,912,818 B2; Canadian Patent 2,419,706; European Patent EP 1 404 939 B1) to secure monolithic tempered glass with exceptional holding force.

The system applies controlled downward pressure via two glass-retaining aluminum extrusions and a flat stainless steel bar. As socket head cap bolts pull the bar down, angled extrusions engage the tapered groove in the rail, creating wedge pressure that generates more than 900 lbs. of holding force in the 9" (228.6 mm) corner rail—delivering rock-solid retention across full-length door rails.

Key benefits and long-tail features:

• Fast installation for glass doors — experienced installers can prepare a door in under ten minutes.
• Comes fully fabricated with End Caps installed and ready-to-install right from the carton.
• Standard Adjustable Door Alignment System (top and bottom) allows ±1/8" (3.2 mm) adjustment toward or away from the jamb without removing the door.
• Low-profile adjustable slide supports non‑standard pivot setbacks and out-of-square openings.
• Models accept 3/8" or 1/2" (10 or 12 mm) glass; available models for up to 3/4" (19 mm) glass.
• Rigid single-component housing resists shifting or loss of adjustment over time.
• Internal components remain in place during installation; pads designed for longevity in extreme environments.

NOTE: All Wedge-Lock® Door Rails include the built-in Jamb Alignment Block. Arms, pivots, closer arms and floor/overhead pivots must be ordered separately to meet job requirements.

After installation, remove the End Cap to access three socket head cap bolts: the center bolt secures the adjustable slide; the two outer bolts adjust the slide ±1/8" (3.2 mm). Matching finish keyed cylinders or thumbturns are ordered separately for models with locks.

CRL Wedge-Lock® Door Rails are available in several standard architectural finishes and can be quoted in custom finishes and widths. Rail specifications, templates and hardware packages are available from CRL Technical Sales.

<
