CRL Brushed Stainless GSDH1 Series Single Bottom Rolling Door Installation Assembly - 118"

• Kits Contain All Necessary Hardware to Complete the Installation
• One Pair of Rollers Can Accommodate Doors Weighing Up to 286 Pounds (130 kg)
• Brushed or Polished Stainless Steel Finishes
• Configurations for a Single Rolling Door or Bi-Parting Rolling Doors
• Use Monolithic Tempered Glass

There are two configurations of

GSDH1 Series Kits

for glass doors. Both come with everything you need (except the tempered glass and handle hardware) to complete the installation, including Top and Bottom Track, Top Guides, Top Guide Roller Stops, End Covers, and the Bottom Rollers. Kits are available in a Brushed or Polished Stainless Steel finishes for both single and bi-parting rolling doors.

For more information on this versatile and easy-to-install system, contact our Technical Sales Department.

Laminated glass should not be used with the GSDH System.

Four holes and two notches per panel. Glass templates included in kits.

- All customers who in any way utilize this product are solely responsible to consult a structural engineer to determine the suitability of the product for the intended use and site conditions. All installers must be qualified and have professional knowledge about compliance with local, state and federal regulations, safety factors, and the appropriate choice of fixing material and procedures.

Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.

Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
