CRL Brushed Stainless Bi-Part Bottom-Rolling Sliding Glass Door
CRL Brushed Stainless Bi-Part Bottom-Rolling Sliding Glass Door
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# 4SDR21BBS
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Brushed Stainless Steel
Height
4 in. (102 mm)
Maximum Door Height
108 in. (2743 mm)
Maximum Door Width
48 in. (1219 mm)
Maximum Panel Weight
234 lbs. (106.1 kg)
Overview
- With 4" Square DR4S Series Door Rails
- Available in Seven Architectural Finishes
The CRL SDR Bottom Rolling Sliding Door System (SKU: 4SDR21BBS) features 4" (102 mm) square top and bottom rails and uses the proven Wedge-Lock® Glass Securing System. DR4S Series door rails are used for both door and fixed panels and are custom fabricated to your specifications. Doors are available with or without locks in the bottom rail.
Performance specifications: maximum door width 48" (1.22 m); maximum door height 108" (2.74 m); maximum door weight 234 lb (106 kg). Ideal for commercial and high-end residential applications requiring a durable bottom rolling sliding door system for glass panels.
Finish & options: Available in seven architectural finishes. Choose clad, brushed stainless, polished stainless, polished brass, or satin brass finishes.
Product Warning:
- Clad finishes
- Brushed Stainless
- Polished Stainless
- Polished Brass
- Satin Brass
Stainless Steel Advisory:
Stainless steel is corrosion resistant but not rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in Technical References for details.
Why choose the CRL SDR Bottom Rolling Sliding Door System (4SDR21BBS)? Custom-fabricated DR4S rails, Wedge-Lock® glass securing, multiple architectural finishes, and optional bottom-rail locks provide a secure, attractive solution for glass sliding doors.
Contact CRL or your local distributor to request a quote or technical drawings for SKU 4SDR21BBS.
Specifications
CAD Drawings - pdf
