CRL Large Capacity Counter Mounted Transaction Drawer

Buy More, Save More!

Product quantity Discount
Buy 3 2% off
Buy 5 4% off
Buy 10 6% off
Buy 15 8% off
Buy 20 10% off

Overview

SKUTD1724C3
Pack Size1
Shipping LimitationsShipping Quote Required
Code CompliancesUL 752
Depth24 in. (609.6 mm)
Finish/Color:Brushed Stainless Steel
Height9-7/8 in. (250.8 mm)
MaterialStainless Steel
Protection Level3
Width17 in. (431.8 mm)

Description

Product Details

  • Available in Thru-Wall and In-Counter Models
  • Styles for All Popular Mounting Options Including Thru-Wall and Counter Mount Types
  • Level 1 Drawer With Cover Plate - Level 3 Front/Rear Bullet Resistant Protection

Our CRL Large Capacity Transaction Drawer is available in two different configurations; one designed to be installed into a counter, one designed to allow thru-wall installation requirements. Simply choose the drawer that best fulfills your installation requirements.

Suitable for drive-up and walk up service, this weather resistant drawer has a lexan lid to allow clear view of contents while preventing direct entry of outside air. Stainless steel front panel pivots up as drawer is extended. Latching knob keeps drawer lid locked when closed. Inside measurements of drawer are 12-7/8" (327 mm) wide x 20-3/4" (527 mm) deep x 6-1/4" (159 mm) high. Custom sizes and Level 3 Bullet Resistant versions are available on special order.

SPECIFICATIONS:

Materials: Stainless Steel; Lexan; Bullet Resistant Plastic; Bullet Resistant Fiberglass/Wood Composite

Finish: 11 Gauge Brushed Stainless Steel (Face Plate Only) #4 Finish Black Plastic Laminate

Instructions Included

Counter or Wall Fabrication Required

Stainless Steel Advisory:

Although Stainless Steel is resistant to corrosion, it is not rust or stain proof. CRL recommends periodic maintenance to help maintain its factory finish. For more information, view the Stainless Steel Disclaimer found in the Technical References section below.
