CRL Matte Black Grade 1 Heavy-Duty Entry Lever Lock - Schlage® 6-Pin

CRL Matte Black Grade 1 Heavy-Duty Entry Lever Lock - Schlage® 6-Pin

Regular price $183.26 CAD
Regular price Sale price $183.26 CAD
Sale Sold out
Shipping calculated at checkout.
Quantity
Item# D60ENTMBL
Shipping Weight: 4.0 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Backset
2-3/4
Category
Door Accessories
Certification
ANSI A156.2 Grade 1
Clutch Feature
Yes
Door Thickness Range
1-3/8" To 1-3/4"
Door Type
Aluminum, Wood, Hollow Metal
Finish/Color
Matte Black
Fire Rating Hour
3
Function
Entrance
Handing
Non Handed and Reversible
Handle Length
4-5/8
Includes
Strike
Keyway
Schlage (R) 6-Pin
Operation Type
F109 Entrance Lever
Projection
2-1/2
Rosette Base Height
11/16
Rosette Base Width
3-3/8
Strike Height
4-7/8
Strike Width
1-1/4
Type
Heavy Duty Lever Lockset
UL Listed
Yes

Overview

  • Schlage® 'C' 6-Pin Keyway
  • Clutch Feature (Grade 1) — prevents latch failure from excessive torque
  • ANSI A156.2 Grade 1
  • 3 Year Warranty
  • UL Listed, 3-hour fire rating

These CRL heavy-duty commercial Grade 1 and 2 lever locksets are non-handed and reversible. The Grade 1 clutch feature disengages the outer lever when locked to prevent latch failure from forced entry attempts — a key security differentiator for commercial exterior doors.

These locksets are UL Listed with a 3-hour fire rating and fit door thicknesses from 1-3/8" to 1-3/4" (35 to 45 mm) with a 2-3/4" (70 mm) backset. Options include a Schlage® 'C' 6-pin keyway (SKU D60ENTMBL) or a 7-pin Small Format Interchangeable Core (SFIC). Strike: ANSI 1-1/4" x 4-7/8" (32 x 124 mm). Long-tail search terms: heavy-duty commercial Grade 1 lever lockset, 3-hour fire-rated UL listed commercial lockset, Schlage C 6-pin keyway commercial lock.

ENTRANCE FUNCTION DESCRIPTION: Pushing the inside button locks the outside trim and requires a key to unlock. Pushing and twisting the button locks the outside lever and always requires a key to unlatch. Inside lever always allows free egress.

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images are of the actual product or a close representation; colors may vary by monitor.


Order the D60ENTMBL heavy-duty Grade 1 entrance lockset today for reliable, fire-rated commercial door security.
