CRL Matte Black Laguna Series Wall Mount Bi-Parting Slider with Softbrake Kit
CRL Matte Black Laguna Series Wall Mount Bi-Parting Slider with Softbrake Kit
Regular price
$3,163.34 CAD
Regular price
Sale price
$3,163.34 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# LSWM8MBL
Shipping Weight: 41.0 Pounds
Shipping Limitations: None
Warning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Shipping Weight: 41.0 Pounds
Shipping Limitations: None
This Product Ships Free!
Compliance and RestrictionsWarning: Reproductive Harm
www.p65warnings.ca.gov
Minimum Order Quantity: 1
Unit of Measure: Pack of 1
Description
| Anti-Lift Yes | Attachment Flush, Surface |
| Door | Configuration Double Door |
| Finish/Color | Matte Black |
| Glazing Thickness | 3/8 in. or 1/2 in. (10 mm or 12 mm) |
| Glazing | Type Tempered Monolithic |
| Material | Stainless Steel (Alloy 316) |
| Maximum Door Height 98-7/16 in. | (2500 mm) |
| Maximum Panel Weight 220 lbs. | (100 kg) |
| Minimum Door Width 37-13/16 in. | (960 mm) |
| Mounting | Application Wall |
| Track Diameter 1-1/4 in. | (32 mm) |
| Track Length 104 in. | (2642 mm) |
Overview
The CRL Laguna Series Wall Mount Bi-Parting Slider with Softbrake Kit is an essential solution for installing bi-parting sliding doors with precision and ease.
Featuring a Softbrake braking system, this kit ensures smooth control of the last 2-1/4" (57 mm) of door travel, while its improved anti-lift design provides added security.
Constructed with durable Alloy 316 stainless steel, the assembly includes all necessary hardware for installation with 3/8" or 1/2" (10 or 12 mm) tempered glass, though the glass itself is not included.
Additionally, it offers versatile installation options with Surface Mount or Flush Mount Fittings and a vertical adjustment for optimal door alignment.
Note that laminated glass is incompatible and structural consultation is strongly recommended to ensure safe and compliant installation.
Featuring a Softbrake braking system, this kit ensures smooth control of the last 2-1/4" (57 mm) of door travel, while its improved anti-lift design provides added security.
Constructed with durable Alloy 316 stainless steel, the assembly includes all necessary hardware for installation with 3/8" or 1/2" (10 or 12 mm) tempered glass, though the glass itself is not included.
Additionally, it offers versatile installation options with Surface Mount or Flush Mount Fittings and a vertical adjustment for optimal door alignment.
Note that laminated glass is incompatible and structural consultation is strongly recommended to ensure safe and compliant installation.
Specifications
Installation Instructions
CAD Drawings - pdf
CAD Drawings - dwg
