• Polished stainless steel 1" glass-mounted straight push/pull handle for 3/8-3/4" glass, 28" C-C (SKU CM10X28PS)
1 1

CRL

CRL Polished Stainless 10x28 Back-to-Back Push-Pull Glass Door Handle

CRL Polished Stainless 10x28 Back-to-Back Push-Pull Glass Door Handle

$159.65 CAD
$159.65 CAD
Sale Sold out
Shipping calculated at checkout.
View More Information Buy More, Save More
Item# CM10X28PS
Shipping Weight: 2.8 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Diameter
1 in. (25 mm)
Finish/Color
Polished Stainless Steel
Glazing Thickness
3/8 in. To 3/4 in. (10 mm To 19 mm)
Mounting Type
Back-to-Back
Pull Mounting Center To Center
10 in. (254 mm)
Push Mounting Center To Center
28 in. (711 mm)

Overview

  • For use with 3/8" to 3/4" (10 to 19 mm) monolithic tempered glass
  • 1" (25.4 mm) diameter stainless steel or brass tubing
  • Five architectural finishes for modern glass doors
  • Glass-mounted straight push/pull handle combination for storefronts and interior glass doors

This CRL Glass Mounted Straight Push/Pull Handle Combination (SKU: CM10X28PS) fits 3/8"–3/4" tempered glass and is available in two sizes and multiple attractive architectural finishes. Ideal as a heavy-duty glass door handle or storefront push/pull solution for commercial and residential glass doors.


SPECIFICATIONS:
For Use With: 3/8" to 3/4" (10 to 19 mm) glass (monolithic tempered recommended)
Construction: 1" (25 mm) diameter stainless steel or brass tubing
Glass Fabrication Required:
Three 5/8" (16 mm) diameter holes positioned at:
10" (254 mm) center-to-center
12" (305 mm) center-to-center
28" (711 mm) center-to-center
33" (838 mm) center-to-center
Offset: 3" (76 mm) center-to-center
Optional: 1-1/4" (32 mm) diameter available on special order

INCLUDES:
2 each: through-bolts for glass mounting
4 each: 1-1/4" (32 mm) diameter matching finish metal washers and rubber gaskets

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your monitor's color calibration.

Stainless Steel Advisory:
Stainless steel is corrosion resistant but not entirely rust- or stain-proof. CRL
