Polished Stainless Steel CRL 1202 Post-Mounted Gate w/ In-Rail Closer
Polished Stainless Steel CRL 1202 Post-Mounted Gate w/ In-Rail Closer
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# 1202P4PSC
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Polished Stainless Steel
Gate Opening Width
Max. 40 in. (Max. 1016 mm)
Glass Included
No
Glazing Thickness
3/8 in. & 1/2 in. (10 mm To 12 mm)
Height
42 in. To 72 in. (1067 mm To 1829 mm)
Overview
- Heavy-duty glass gate with optional cap rail
- Attractive design and smooth, functional operation
- Unique in-rail closing device concealed in the vertical post
- Round vertical edge gate pivot post prevents finger pinch
- Fits 3/8" or 1/2" (10 or 12 mm) tempered glass
- Double-acting (no hold open) swing gate design
- Optional locks available
Our Swinging Gates (SKU: 1202P4PSC) are engineered for commercial and residential glass railing systems and integrate seamlessly with the GRS Glass Rail System or Wedge-Lock® Door Rail System. The top and bottom of the gate swing on heavy-duty ball-bearing pivots for reliable performance.
Minimum required height: 40". Maximum gate size: 40" x 70". Made for tempered glass panels (3/8" or 1/2").
Engineers designed a concealed in-rail closing mechanism inside the vertical post, eliminating large floor enclosures. The closer automatically returns the gate to closed position and features adjustable closing speed. NOTE: Available by custom order only. Most orders can be fabricated in five business days at our Los Angeles, California facility. Contact our Technical Sales Department for assistance.
Product Warning:
All Swinging Gates are custom fabricated to your specifications.
Stainless Steel Advisory:
Although stainless steel is highly corrosion resistant, it is not rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in the Technical References section for more information.
Highlight: ideal glass gate for residential and commercial use, tempered glass swinging gate, concealed in-rail closer—custom fabricated to order. Contact us to request a quote or technical assistance.
Specifications
CAD Drawings - pdf
