• CRL 0TS1PS polished stainless overhead track sliding door system, single-panel 1-track for 3/8 in (10 mm) glass, flush bottom
1 1

CRL

CRL Polished Stainless Overhead Track Sliding Door Hardware for Glass

CRL Polished Stainless Overhead Track Sliding Door Hardware for Glass

Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 0TS1PS
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Configuration
Single Track 1 Panel Slide
Finish/Color
Polished Stainless Steel
Glazing Thickness
3/8 in. (10 mm)
Maximum Panel Width
72 in. (1829 mm)
Series
OT Overhead Track Slider

Overview

  • Four-Roller Units Silently Move the Door Rails
  • Provides a Flush Bottom Surface
  • Available in Several Configurations and Architectural Finishes

CRL Overhead Track Sliding Door Systems — SKU 0TS1PS — are engineered for smooth, quiet operation. Units are available in four standard configurations and hang each sliding panel from two Cat. No. 0TCA Carriage Assemblies. Maximum panel weight: 225 lbs (102 kg). Maximum panel width: 72" (1.83 m). Minimum panel width: 25" (635 mm). These systems deliver a flush bottom surface and multiple architectural finishes for commercial and residential overhead track sliding door applications.


NOTE: Available by custom order only. Most orders can be fabricated in five business days at our Los Angeles, California manufacturing facility. Contact our Technical Sales Department.

Most shipping weights are approximate and have not been verified. If exact weight is required to determine shipping costs, request this information from CRL Customer Service before submitting your order. Product images shown are of the actual product or a close representation; colors can vary by monitor and video card settings.

Stainless Steel Advisory:
Although stainless steel is highly corrosion resistant, it is not completely rust- or stain-proof. CRL recommends periodic maintenance to preserve the factory finish. See the Stainless Steel Disclaimer in the Technical References section for maintenance guidance.

For specification help, finish options, or a custom quote for SKU 0TS1PS, contact CRL Technical Sales or request a quote online.
