CRL Polished Stainless Steel Rim Cylinder Housings for SFIC Locks

• Compatible with Any 7-Pin SFIC Type Core
• Available in Several Architectural Finishes

CRL Mortise Housings for 7-Pin Small Format Interchangeable Cores (SFIC) provide a quick, field‑convertible solution to replace mortise keyed cylinders with a 7‑pin Small Format Interchangeable Core system. Use to convert Door Rails with locks, 4" x 10" and 6" x 10" Center Locks, Panic and Deadbolt Handles, or our Locking Ladder Pulls to an interchangeable core configuration. Remove the existing mortise cylinder, select the proper cam, and install the new housing and SFIC core — no special tools required.


CRL Rim Cylinder Housings for 7‑Pin SFIC are standard in select Locking Ladder Pulls or can be installed wherever 7‑pin SFIC mortise or rim housings are needed. Note: SFIC cores are sold separately. SKU: 2CHPS.

ORDERING INFORMATION:
• Each Mortise Housing ships with a 1/2" (12 mm) tall cylinder ring and included cams: one DRA10CAM (installed), one DRACAM, and one DRA610CAM for quick conversions.
• Not compatible with larger removable core systems; designed specifically for 7‑pin SFIC systems only.
• When used with CRL Low Profile Wedge‑Lock® Door Rails, order a DRA256 Series Cylinder Ring separately.
• SFIC Cores must be ordered separately.

Stainless Steel Advisory:

Choose CRL 7‑Pin SFIC mortise housings for fast conversions, broad compatibility with SFIC cores, and multiple architectural finishes. Order now or contact CRL Customer Service for assistance.
