CRL 150 Series 83" Satin Anodized Heavy-Duty Continuous Door Hinge
CRL 150 Series 83" Satin Anodized Heavy-Duty Continuous Door Hinge
Regular price
$349.22 CAD
Regular price
Sale price
$349.22 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# 15083A
Shipping Weight: 10.45 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: 10.45 Pounds
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Satin Anodized
Includes
Pack of Screws
Length
83 in. (2108.2 mm)
Maximum Door Weight
600 lbs. (272.2 kg)
Replacement Screw Pack
RSC100A
Series
150
Width
3-1/16 in. (77.8 mm)
Overview
- Standard Duty Hinges for Doors Weighing Up to 200 Lbs. (90 kg)
- Heavy-Duty Hinges for Doors Weighing Up to 600 Lbs. (272 kg)
- Available in Satin Anodized and Dark Bronze Anodized Finishes
These CRL Full Surface Continuous Hinges are full-length continuous hinges engineered for reliable, load-bearing performance. Load bearing blocks are spaced every 5-1/8" (130 mm) on the Standard Duty model and every 2-9/16" (65 mm) on the Heavy-Duty model to distribute weight evenly and reduce wear. Stocked in 83" (2.11 m) lengths and available in satin anodized and dark bronze anodized finishes, each hinge ships with a pack of installation screws; replacement screw packs are available separately.
SKU: 15083A — for ordering or technical questions, contact CRL Customer Service or add to cart now.
Specifications
Installation Instructions
