Product Details
- D2203 Series
- With D649 Ball Bearing Wheels
- An Excellent Choice for Any Project
- Choose From Two Styles of Upper Channel
- Available in Up to Six Finishes
- 12' (3.66 m) Length
CRL's 12' (3.66 m) Low Profile Rolling Track Assemblies are packaged to contain the Extrusions, Wheels, and Guides you will need to complete your custom project. Designed for 1/4" (6 mm) tempered glass doors, these Track Assemblies have long been a popular choice for display cases, trophy cases, china cabinets, as well as cases for any retail store application. Choose from either Nylon or Steel Ball Bearing Wheel Assemblies for years of smooth and reliable service. The versatility of this track system allows for design flexibility. Optional locking hardware is available. For dry glazing with 1/4" (6 mm) glass use Cat. No. GC728C Vinyl (sold separately).
NOTE: Maximum suggested panel size is 36" W x 48" H (914 mm x 1.22 m)
Components for D2203A
D602A (x1)
D603A (x1)
D610A (x12)
D649 (x12)
D652 (x1)
D9650 (x1)
Product Warning:
Stock lengths must ship common carrier unless specifically cut for UPS shipment.
If you need a very tight fit, you should figure your own dimensions. The dimensions shown are just guideline dimensions that are satisfactory to most installers.
D2203 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-1/8"
D2204 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-1/8"
D2300 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2301 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2303 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2305 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-3/8"
D2306 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-5/8"
D2307 Series = Rolling Track Assembly : Glass Height = Opening Minus 1-5/8"
