CRL Satin Anodized XOX Sliding Window, Vinyl 1/8 & 1/4, No Screen

• Glass and Screen Panels on Either End Can be Opened as Required
• For Light Duty Applications of 50 or Fewer Uses Per Day
• Available in Vertical and Horizontal Formats
• Each Unit is Customized to Fit Your Needs

This CRL Horizontal Sliding Service Window (SKU: SW5000A) features two sliding side panels plus a fixed center panel—the center panel is twice the width of each sliding panel so both sides can be opened simultaneously. Designed as a light-duty pass-through window for retail or service counters, it ships with vinyl glazing for 1/8" (3 mm) or 1/4" (6 mm) glass and may be ordered pre-glazed with 1/8" or 1/4" tempered glass, or 1/2" (12 mm) insulating glass. NOTE: If ordered with keyed locks, sliding screens will be installed in the center channel. Surround frame not available for insulating glass models. An overhang is recommended for exterior installations.

Key differentiators:

• Customizable sizes and configurations—vertical or horizontal formats
• Multiple glazing options: vinyl-supplied, tempered glass, or insulated glass
• Light-duty design rated for up to 50 operations per day—ideal for service counters and pass-through applications
• Durable extruded aluminum construction with multiple finish choices

SPECIFICATIONS:
Materials: Extruded Aluminum; Tempered Safety Glass (on some models); Fiberglass Screen (on some models)
Finishes: Satin Anodized, Duranodic Bronze, RAL Powder Paint or Kynar Paint
Glazing: 1/8" (3 mm) or 1/4" (6 mm) Tempered Glass; 1/2" (12 mm) Insulating Glass (on some models); Vinyl supplied on all models
Instructions Included

Product Warning & Size Limits:

Horizontal Service Window Series SW1600 THRU SW5200 Have these Maximum Sizes:
144" (3.66 m) Wide x 36" (914 mm) High (With Restrictions)
EXAMPLE: A 144" (3.66 m) wide window has a maximum height of only 24" (610 mm).

These Series SW1600–SW5200 units are intended as pass-through windows and are not constructed with storefront extrusions—do not use for other structural applications.

No keyed lock is available
