• CRL SDR bottom-rolling sliding door system (SKU 6SDR2BSA), satin anodized, 4" top / 6" bottom rails, single sliding glass pan
1 1

CRL

CRL Satin Anodized XX Sliding Door System - 4in Top, 6in Bottom Rail

CRL Satin Anodized XX Sliding Door System - 4in Top, 6in Bottom Rail

Shipping calculated at checkout.
View More Information Buy More, Save More
Item# 6SDR2BSA
Shipping Weight: NA
Shipping Limitations: No UPS - Common Carrier Only
Request A Quote For A Shipping Rate
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Door Configuration
X- or -X
Finish/Color
Satin Anodized
Maximum Door Height
108 in. (2743 mm)
Maximum Door Width
48 in. (1219 mm)
Maximum Panel Weight
234 lbs. (106.1 kg)
Panel Count
1

Overview

  • 4" Square DR4S Series top rails and 6" Square DR6S Series bottom rails
  • Available in seven architectural finishes

The CRL SDR Bottom Rolling Sliding Door System (SKU: 6SDR2BSA) features 4" (102 mm) square top rails and 6" (152 mm) square bottom rails and uses the Wedge-Lock® Glass Securing System from the DR4S and DR6S Series for secure, reliable glass retention. Custom fabricated to your specifications, the system can be ordered with or without integrated bottom-rail locks. Designed for interior and exterior sliding glass doors, maximum door width is 48" (1.22 m), maximum door height is 108" (2.74 m), and maximum door weight is 234 lb (106 kg).

Most shipping weights are approximate and have not been verified. If the exact weight is needed to determine shipping costs, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and monitor settings.


Order the CRL SDR Bottom Rolling Sliding Door System (6SDR2BSA) today for secure, customizable bottom-rolling sliding glass doors.
