CRL Satin Brass 6" Square Glass Door Rail w/ Lock - 1/2" Glass

• Custom length for 1/2" (12 mm) glass
• Use monolithic tempered glass
• Patented Wedge-Lock® Glass Securing System (high-strength glass door rail)
• Models to fit 3/8" to 3/4" (10 to 19 mm) glass
• Available in several stock architectural finishes — custom finishes available
• Available with or without locks
• Matching sidelite rails available

An innovative glass entrance solution, the CRL Wedge-Lock® Door Rail System (SKU DR6SSB12CL) features the exclusive Wedge-Lock® Securing System (U.S. Patents 6,434,905 and 6,912,818 B2; Canadian Patent 2,419,706; European Patent EP 1 404 939 B1). This patented wedge-action design applies downward pressure via two glass-retaining aluminum extrusions and a flat stainless steel bar. As the bar is tensioned with socket head cap bolts, angled extrusions engage an angled groove in the rail, producing very high clamping force (more than 900 lbs in the 9" corner rail) for a secure glass-to-rail connection — ideal for heavy-duty commercial glass doors and frameless glass storefronts.

The Wedge-Lock® system also reduces installation time. Experienced installers can prepare a door for hanging in under ten minutes. Rails ship completely fabricated and ready-to-install with end caps preinstalled. After mounting the rail, attach the door arm or pivot (not included) to the adjustable door alignment slide already assembled in the rail.

The standard adjustable door alignment system (top and bottom rails) allows +/-1/8" (3.2 mm) adjustment toward or away from the jamb without removing the door. Adjustment access is via removable end caps revealing three socket head cap bolts: the center secures the slide; the outer two provide the 1/8" in/out adjustment. The low-profile slide accommodates pivots with slotted grooves and can be fabricated for vertically out-of-square openings.

Key differentiators:

• High clamp force Wedge-Lock® action for superior glass retention — suitable for commercial frameless glass doors and glass storefront entrances
• Single-component rigid housing — will not shift or fall out of adjustment over time
• Internal components remain in place during installation for faster, cleaner installs
• Durable glass securing pads designed for longevity in extreme environments

NOTE: All Wedge-Lock® Door Rails include the built-in jamb alignment block; arms and pivots must be ordered separately to meet job requirements.

Rails are offered in several standard finishes and can be quoted in custom finishes and widths. Rail specifications, templates, and hardware packages are available from CRL Technical Sales.

ORDERING INFORMATION:

• All door rails are supplied with the standard Kwik-Adjust™ Pivot Alignment System. Closer arms and floor or overhead
