CRL Satin Brass 4" Square Glass Door Rail for 3/8" Glass with Lock

• Custom length for 3/8" (10 mm) glass
• Use monolithic tempered glass
• Patented Wedge-Lock® glass securing system (U.S., Canadian, EU patents)
• Models to fit 3/8" to 3/4" (10 to 19 mm) glass
• Available in several stock architectural finishes; custom finishes available
• Available with and without locks
• Matching sidelite rails available

SKU: DR4SSB38CL

Our CRL Wedge-Lock® Door Rail System features the exclusive Wedge-Lock® Securing System (U.S. Patents 6,434,905 and 6,912,818 B2; Canadian Patent 2,419,706; European Patent EP 1 404 939 B1). This frameless glass door rail for tempered glass secures the panel by pulling two glass-retaining aluminum extrusions together via a flat stainless steel bar and socket head cap bolts, creating exceptional clamping force in the rail.

Actual product height: 4-1/16” (103 mm)

Key benefits:

• Fastest installation time of any door rail system—experienced installers can prepare a door in under ten minutes
• Comes completely fabricated and ready-to-install with end caps installed
• Adjustable Door Alignment System (standard top and bottom) provides ±1/8" (3.2 mm) adjustment without removing the door
• Rigid single-component housing resists shifting and stays in adjustment over time
• Internal components remain in place during installation—no removal required
• Glass securing pads designed for long life in extreme environments
• Built-in jamb alignment block (arms and pivots ordered separately to meet job requirements)

Installation and adjustment: remove the end cap to access three socket head cap bolts—center bolt secures the slide; outer bolts adjust the slide ±1/8" (3.2 mm). Low-profile adjustable slide allows pivot placement other than the American Standard setback for out-of-square openings.

Ordering information:

• Supplied with standard Kwik-Adjust™ Pivot Alignment System; closer arms and floor or overhead pivots must be ordered separately
• Models with locks include the lock mechanism; keyed cylinders or thumbturns ordered separately
• End caps included in stock lengths; specify rail length (including end caps) when ordering custom lengths

Finishes and support: standard architectural finishes available; custom finishes and widths quoted upon request. Rail specifications, templates and hardware packages available from CRL Technical Sales via e-mail.

Product warning: Comes standard with jamb alignment block; arms and pivots must
