CRL Satin Brass 3/8" Tapered Glass Door Rail w/ Lock - Custom Length

• Custom length for 3/8" (10 mm) monolithic tempered glass
• Patented Wedge-Lock® glass securing system (fastest installation; secure attachment)
• Low profile rails: 2-5/16" (59 mm) tall × 1-1/2" (38 mm) wide
• Available in several stock architectural finishes; custom finishes available
• Available with or without locks; matching sidelite rails available

CRL Low Profile Door Rail combines a slim 2-5/16" (59 mm) height with the patented Wedge-Lock® Glass Securing System (U.S. Patents 6,434,905 and 6,912,818 B2; Canadian Patent 2,419,706; European Patent EP 1 404 939 B1). Each rail ships ready-to-install with End Caps, installation instructions, and adjustment wrenches.

NOTE: Actual product height: 2-5/16” (59 mm).

The Wedge-Lock® system delivers a secure attachment and the fastest install time among door rails—experienced installers can prepare a door in under ten minutes. Rails arrive fully fabricated; simply attach the door arm or pivot (not included) to the adjustable door alignment slide already assembled in the rail.

The built-in Adjustable Door Alignment System lets you shift the door ±1/8" (3 mm) toward or away from the jamb without removing the door (standard on top and bottom rails). To adjust after installation, remove the End Cap to access three socket head cap bolts—the center secures the slide; the outer two adjust the slide in or out. The low-profile adjustable slide accommodates pivots with slotted grooves and can be fabricated for vertically out-of-square openings.

Why choose Wedge-Lock® Door Rails:

• Accepts 3/8" to 3/4" (10–19 mm) glass
• Rigid single-component housing that resists shifting or loss of adjustment over time
• Internal components remain in place during installation
• Durable glass-securing pads for extreme environments

NOTE: All Wedge-Lock® Door Rails feature a built-in jamb alignment block; arms and pivots must be ordered separately to meet job requirements.

Finish and ordering: rails come in several standard finishes and can be quoted in custom finishes and widths. Rail specifications, templates, and hardware packages are available from CRL Technical Sales via e-mail.
