CRL-U.S. 250 Series Anodized Aluminum-Bronze Narrow Stile Butt Hinge
CRL-U.S. 250 Series Anodized Aluminum-Bronze Narrow Stile Butt Hinge
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# HE21522
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized Class 1
Overview
- Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed-alike cylinders
- Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit available (glass not included)
- 9-1/2" (241 mm) bottom rail option for A.D.A. and Title 24 applications
- Custom fabricated to accept a wide range of optional hardware applications
This Custom Narrow Stile Entrance Door (SKU: HE21522) features 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 7-1/2" (191 mm) bottom rail. Standard preparation includes stiles for butt hinge hardware and glass stops sized for 1/4" (6 mm) tempered glass (glass sold separately). Built for storefront and commercial entrances, this narrow stile door supports custom fabrication for optional locks, pivots, and specialty hardware for storefront, office, and retail applications.
Note: Included protruding hardware (handles, pivots, etc.) is boxed separately and must be installed by the customer to prevent transit damage. Door widths under 36" (914 mm) may not meet A.D.A. inspection requirements.
Why choose this door? Ideal for tempered-glass storefront installations needing narrow stile sightlines, keyed-alike security, and ADA-compatible bottom rail options.
Contact us to request a quote, confirm ADA compliance, or order SKU HE21522.
Specifications
