CRL-U.S. 550 Black Anodized Bronze Butt Hinge, Wide Stile, Closer-Ready
CRL-U.S. 550 Black Anodized Bronze Butt Hinge, Wide Stile, Closer-Ready
Regular price
$1,503.71 CAD
Regular price
Sale price
$1,503.71 CAD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# DC51522
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized Class 1
Overview
- 7" (178 mm) bottom rail; 10" (254 mm) bottom rail available to comply with A.D.A. and Title 21 applications
- Custom fabricated to accept optional hardware applications; ready for butt hinge hardware
- Includes standard push/pull and hanging hardware, MS hookbolt lock, and two keyed‑alike cylinders
- Accommodates 1/4" (6 mm) tempered glass (by others) with option for 1" (25 mm) tempered insulating unit — glass not included
This Custom Wide Stile Entrance Door (SKU: DC51522) is built with 5-1/2" (140 mm) stiles, a 6" (152 mm) top rail, and a 7" (178 mm) bottom rail. Optional 10" (254 mm) bottom rail is available for ADA-compliant and Title 21 installations. Standard features include stiles for butt hinge hardware and glass stops for 1/4" tempered glass. Door is custom fabricated to accept a wide range of optional hardware applications, making it ideal for commercial storefronts and accessible entrance projects.
Customer must install included protruding hardware (handles, pivots, etc.), which is boxed separately to prevent damage in transit. Note: door widths under 36" (914 mm) may not pass A.D.A. inspection.
Order SKU DC51522 today — contact CRL for a quote or to confirm ADA/Title 21 configurations and glass options.
Specifications
