CRL-U.S. 550 Wide Stile Aluminum Door Butt Hinge, Clear Anodized

• Includes Standard Push/Pull, Hanging Hardware, MS Hookbolt Lock, and Two Keyed-Alike Cylinders
• Accommodates 1/4" (6 mm) tempered glass or optional 1" (25 mm) tempered insulating unit (glass not included)
• 7" (178 mm) bottom rail; 10" (254 mm) bottom rail available to comply with A.D.A. and Title 21 applications
• Custom fabricated to accept a wide range of optional hardware applications

Custom Wide Stile Entrance Door (SKU: DC51511) is built with 5-1/2" (140 mm) stiles, a 6" (152 mm) top rail, and a 7" (178 mm) bottom rail. Standard preparation includes stiles for butt hinge hardware and glass stops for 1/4" (6 mm) tempered glass (by others). Designed for commercial and storefront use, this door accepts optional hardware and upgrades for enhanced security and accessibility.

Note: Included protruding hardware (handles, pivots, etc.) ships boxed separately to prevent transit damage and must be installed by the customer. Door widths less than 36" (914 mm) may not pass A.D.A. inspection.

Key differentiators: MS Hookbolt lock and two keyed-alike cylinders for simplified access control, optional 10" bottom rail for ADA compliance, and custom fabrication to accept specialty hardware. Order SKU DC51511 or contact us for custom options.
