CRL-U.S. Aluminum 550 Clear Anodized Entrance Door Butt Hinge Pair
CRL-U.S. Aluminum 550 Clear Anodized Entrance Door Butt Hinge Pair
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# DC52411
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Clear Anodized Class 1
Overview
- 9-1/2" (241 mm) bottom rail option for A.D.A. and Title 21 compliance — ideal for accessible commercial entrances
- Includes active and inactive leaf with all standard hardware for a complete entry solution
- Custom fabricated to accept a wide range of optional hardware applications (locks, closers, pivots, pull handles)
This Custom Wide Stile Entrance Door (SKU: DC52411) features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 6-1/2" (165 mm) bottom rail. Designed for commercial glass entry installations, the door includes stiles configured for butt hinge hardware and glass stops sized for 1/4" (6 mm) tempered glass (glass supplied by others). The assembly is ready for custom fabrication to accommodate numerous optional hardware packages.
Note: Protruding hardware (handles, pivots, etc.) is boxed separately to prevent transit damage and must be installed on site by the customer or installer.
Order the DC52411 custom wide stile entrance door today to get an ADA-ready, commercial-grade glass entry solution — contact sales to confirm dimensions and optional hardware compatibility.
Specifications
BIM Objects - rvt
