CRL-U.S. Aluminum 550 Geared Hinge Entrance Door - Panic/Overhead
CRL-U.S. Aluminum 550 Geared Hinge Entrance Door - Panic/Overhead
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# DZ51922
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized Class 1
Overview
- Selected panic hardware and one cylinder ordered and added separately
- Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit can be fabricated (glass not included)
- 6-1/2" (165 mm) bottom rail
- Custom fabricated to accept a wide range of optional hardware applications
- Includes standard panic pull and hanging hardware (protruding hardware boxed separately to prevent transit damage)
This Custom Wide Stile Entrance Door (SKU: DZ51922) features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 6-1/2" (165 mm) bottom rail. Built for storefront and commercial entrance applications, it ships ready for Gear Hinge hardware and has glass stops for 1/4" (6 mm) tempered glass (by others). The door is custom-fabricated to accept optional panic, lock, and specialty hardware for high-traffic commercial use.
Note: Customer must install included protruding hardware (handles, pivots, etc.) boxed separately. Door widths under 36" (914 mm) may not meet ADA inspection requirements.
Order SKU DZ51922 or contact us for custom hardware options and shipping weight details.
Specifications
BIM Objects - rvt
