CRL-U.S. Aluminum 550 Offset Pivot Wide-Stile Door w/ Overhead Closer

• 9-1/2" (241 mm) bottom rail installed to comply with A.D.A.
• Custom fabricated to accept optional hardware applications
• Includes standard push/pull, hanging hardware, MS Hookbolt lock, and two keyed-alike cylinders
• Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit available (glass not included)

This Custom Wide Stile Entrance Door (SKU: DE51171) features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 9-1/2" (241 mm) ADA-compliant bottom rail. The door is prepped with stiles for offset pivot hardware and glass stops sized for 1/4" (6 mm) tempered glass (glass supplied by others). Built for commercial applications, it is ready for custom fabrication to accept a wide range of optional hardware such as MS hookbolt locking systems and keyed-alike cylinder configurations.

Included protruding hardware (handles, pivots, etc.) ships boxed separately to prevent transit damage and must be installed by the customer. Note: door widths under 36" (914 mm) may not meet A.D.A. inspection requirements.

Order SKU DE51171 today to get a customizable, ADA-ready commercial entrance solution—contact customer service for glass options and exact shipping weight.
