CRL-U.S. Aluminum 550 Wide Stile Anodized Bronze Butt Hinge Pair
CRL-U.S. Aluminum 550 Wide Stile Anodized Bronze Butt Hinge Pair
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# CZ52422
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized Class 1
Overview
- Custom fabricated to accept optional hardware applications for commercial entrances
- Includes active and inactive leaf with standard concealed vertical rod panic hardware for secure egress
- 9-1/2" (241 mm) bottom rail installed to comply with A.D.A. requirements
This Custom Wide Stile Entrance Door (SKU CZ52422) features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 9-1/2" (241 mm) ADA-compliant bottom rail. Standard details include stiles prepped for butt hinge hardware and glass stops sized for 1/4" (6 mm) tempered glass (by others). Built for storefront and commercial applications, the door is ready for custom fabrication to accommodate a wide range of optional hardware configurations, including concealed vertical rod panic devices for code-compliant exit hardware.
Customer-installed protruding hardware (handles, pivots, etc.) is boxed separately to prevent transit damage—install after delivery.
Specifications
BIM Objects - rvt
