CRL-U.S. Aluminum 550 Wide-Stile Geared Door Hinge, Concealed Closer

CRL-U.S. Aluminum 550 Wide-Stile Geared Door Hinge, Concealed Closer

Shipping calculated at checkout.
View More Information Buy More, Save More
Item# HE51911
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Clear Anodized Class 1

Overview

  • Accommodates 1/4" (6 mm) tempered glass with option for 1" (25 mm) tempered insulating unit (glass not included)
  • 7-1/2" (191 mm) bottom rail
  • Custom fabricated to accept optional hardware applications
  • Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed‑alike cylinders

This Custom Wide Stile Entrance Door features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 7-1/2" (191 mm) bottom rail. Designed for commercial storefronts and high-traffic entryways, the door includes stiles prepared for Gear Hinge hardware and glass stops for 1/4" (6 mm) tempered glass (by others). Factory-ready for custom fabrication to accommodate a wide range of optional hardware applications and finishes.

Customer must install included protruding hardware (handles, pivots, etc.) boxed separately to prevent transit damage. Note: door widths under 36" (914 mm) may not meet A.D.A. inspection requirements.

SKU: HE51911

Most shipping weights are approximate and have not been verified. If the exact weight is needed in order to determine shipping costs, and shipping costs are required in order for you to complete your order, please request this prior to submitting your order by contacting CRL Customer Service. Product images shown are of the actual product or a close representation. Colors can vary depending on your computer's video card and on how your monitor's color is adjusted.


Specifications

BIM Objects - rvt
Entrance Series 250 400 550 BIM.rvt
