CRL-U.S. Aluminum 550 Wide-Stile Geared Hinge for Overhead Closers

CRL-U.S. Aluminum 550 Wide-Stile Geared Hinge for Overhead Closers

Shipping calculated at checkout.
View More Information Buy More, Save More
Item# DE51911
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
View full details

Product Information

Description

Finish/Color
Clear Anodized Class 1

Overview

  • 9-1/2" (241 mm) bottom rail installed to comply with A.D.A.
  • Custom fabricated to accept optional hardware applications
  • Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit (glass not included)
  • Includes standard push/pull hanging hardware, MS hookbolt lock, and two keyed‑alike cylinders

Custom Wide Stile Entrance Door (SKU DE51911) features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 9-1/2" (241 mm) ADA-compliant bottom rail. Designed for commercial entrances, this custom wide-stile aluminum door ships with glass stops sized for 1/4" (6 mm) tempered glass (glass supplied by others) and is prepped to accept Gear Hinge hardware and a wide range of optional commercial hardware applications.


Included protruding hardware (handles, pivots, etc.) is boxed separately and must be installed by the customer to prevent transit damage. Note: door widths under 36" (914 mm) may not pass A.D.A. inspection.


Most shipping weights are approximate and have not been verified. If exact weight or shipping costs are required to complete your order, contact CRL Customer Service before submitting your order. Product images shown are of the actual product or a close representation. Colors can vary depending on your monitor settings.


Order the DE51911 custom wide-stile entrance door for ADA-compliant commercial applications — contact us to configure hardware and glazing options.

Specifications

BIM Objects - rvt
Entrance Series 250 400 550 BIM.rvt
