CRL-U.S. Aluminum 550 Wide-Stile White KYNAR Door Surface-Mount Closer
Item# DC51552
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Finish/Color
White Kynar
- Includes standard push/pull, hanging hardware, MS Hookbolt lock, and two keyed-alike cylinders — ideal for commercial entrance security
- 7" (178 mm) bottom rail; 10" (254 mm) bottom rail available to comply with A.D.A. and Title 21 applications
- Custom fabricated to accept optional hardware applications for specialty commercial installations
- Accepts 1/4" (6 mm) tempered glass or optional 1" (25 mm) tempered insulating unit (glass not included)
This Custom Wide Stile Entrance Door (SKU: DC51552) features 5-1/2" (140 mm) stiles, a 6" (152 mm) top rail, and a 7" (178 mm) bottom rail. Standard preparation includes stiles for butt hinge hardware and glass stops for 1/4" (6 mm) tempered glass. Door is shipped with protruding hardware (handles, pivots, etc.) boxed separately—customer installation required to prevent transit damage. Note: door widths under 36" (914 mm) may not pass A.D.A. inspection.
Most shipping weights are approximate. If you need exact weight for shipping quotes, contact CRL Customer Service before ordering. Product images are representative; actual colors may vary by monitor.
Order SKU DC51552 or contact us for custom hardware options and ADA-compliant configurations.
BIM Objects - rvt
