Product Details
- C-75 AAMA Rated
- Thermally Broken System for Exceptional Thermal Performance
- Stainless Steel 4-Bar Hinges and Die Cast Cam Locking Handles
- .062" Nominal Wall Thickness with Reinforced Corners with an Aluminum Corner Key
All window units are built for dry glaze with tape at the outside and E.P.D.M. elastomeric wedge at the inside for 1" Glazing (not included). Vent construction is accomplished with tubular thermally broken members, mitered and reinforced with an extruded aluminum corner key, and hydraulically crimped.
Operating Hardware Includes: Standard 4-Bar Stainless Steel Hinges and Cam Locking Handle.
Operating Hardware Includes: Stainless steel 4-bar hinges, and cam locking handles
Optional Hardware Includes: 90 degree 4-bar stainless steel hinge (for egress), 5 knuckle butt hinges, roto operator, limit device, friction adjuster, lift handle lock, access control lock, screens, wicket box Optional Extrusions Include: Head and jamb channels, mulling bars, subsills, corners, nail fin adapters, extruded sill flashing.
