Product Details
- C-75 AAMA Rated Casement Windows and Project-In top Vent
- CW-75 AAMA Rated for Project-Out bottom Vent
- C-90 AAMA Rated for Fixed Windows
- .062 Nominal Wall Thickness
All window units are built for dry glaze with tape at the outside and E.P.D.M. elastomeric wedge at the inside. Vent construction is accomplished with tubular members, mitered and reinforced with an extruded aluminum corner key, and hydraulically crimped.
Operating Hardware Includes: Stainless steel 4-bar hinges, and cam locking handles
Optional Hardware Include: 90 degree 4-bar stainless steel hinge (for egress), 5 knuckle butt hinges, roto operator, limit device, friction adjuster, lift handle lock, access control lock, screens, wicket box, two point locking handles, and security locks
Optional Extrusions Include: Head and jamb channels, mulling bars, subsills, corners, nail fin adapters, extruded sill flashing.
