CRL-U.S. Aluminum 72x84 Narrow-Stile S250 Gear Hinge Door Pair Kynar
Item# DC22871
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: Pair
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Finish/Color
Custom Kynar
- Accommodates 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit accepted (glass not included)
- Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed‑alike cylinders
- 9-1/2" (241 mm) ADA‑compliant bottom rail option for Title 24 / A.D.A. applications
- Custom fabricated to accept a wide range of optional hardware applications
This Custom Narrow Stile Entrance Door (SKU: DC22871) features 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 3-3/16" (81 mm) bottom rail. Designed for storefront and commercial entrances, it ships ready with stiles for gear hinge hardware and glass stops for 1/4" (6 mm) tempered glass (supplied by others). Protruding hardware (handles, pivots, etc.) is boxed separately and must be installed on site to prevent transit damage.
Most shipping weights are approximate and have not been verified. If exact weight is required to determine shipping costs, contact CRL Customer Service before submitting your order. Product images are actual or close representations; colors may vary by monitor settings.
Ideal for commercial storefronts and ADA‑sensitive projects—order SKU DC22871 or contact us for custom hardware options and fabrication details.
BIM Objects - rvt
