CRL-U.S. Aluminum 76 x 86 Clear Anodized Offset Pivot Transom Frame

• 2" x 4-1/2" (50.8 x 114.3 mm) Offset pivot transom frame with tubular jambs — durable extruded aluminum for commercial openings
• 76" x 86" (1.9 x 2.2 m) base frame size (outside dimensions)
• 72" x 84" (1.8 x 2.1 m) door opening for 72" x 84" doors
• Aluminum threshold included for smooth transition and weather resistance

Complete Frame built to accept a 72" x 84" offset pivot concealed vertical rod panic door with surface-mount closer. Constructed with 1S456 tubular jambs and 1S467 header; includes all associated extrusions, weatherstrip, standard hardware, and hardware preparations. All assembly fasteners, standard hardware, and hardware fabrication are included—customer supplies fasteners to attach frame to opening. No modifications offered on standard frames. SKU: FZ7221172.

Order this offset pivot transom frame with tubular jambs and included aluminum threshold — contact us to confirm availability and lead time.
