CRL-U.S. Aluminum 550 Geared Hinge — Wide Stile, Concealed Closer
CRL-U.S. Aluminum 550 Geared Hinge — Wide Stile, Concealed Closer
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# CD51922
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Black Bronze Anodized Class 1
Overview
- 9-1/2" (241 mm) bottom rail installed to comply with A.D.A.
- Custom fabricated to accept a wide range of optional hardware applications
- Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed-alike cylinders
- Designed to accommodate 1/4" (6 mm) tempered glass; option available for 1" (25 mm) tempered insulating unit (glass not included)
This CRL Custom Wide Stile Entrance Door (SKU: CD51922) features 5" (127 mm) stiles, a 5-1/2" (140 mm) top rail, and a 9-1/2" (241 mm) ADA-compliant bottom rail. Built for commercial storefronts and institutional entrances, it includes stiles prepared for Gear Hinge hardware and glass stops for 1/4" (6 mm) tempered glass (glass by others). The door is ready for custom fabrication to support optional hardware such as panic devices, automatic operators, and specialty locking systems.
Customer must install included protruding hardware (handles, pivots, etc.), which is boxed separately to prevent damage during transit. Note: door widths less than 36" (914 mm) may not pass A.D.A. inspection.
Order SKU CD51922 or contact CRL Customer Service to confirm dimensions, hardware compatibility, or to request a quote.
