CRL-U.S. Aluminum 250 Narrow-Stile Geared Hinge, Clear-Anodized

• 9-1/2" (241 mm) bottom rail installed to meet A.D.A. requirements
• Custom fabricated to accept a wide range of optional hardware applications
• Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed-alike cylinders
• Accepts 1/4" (6 mm) tempered glass; optional 1" (25 mm) tempered insulating unit available (glass not included)

CRL Custom Narrow Stile Entrance Door — SKU: CD21911 — Built with 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail, and a 9-1/2" (241 mm) ADA-compliant bottom rail. Standard configuration includes stiles prepared for Gear Hinge hardware and glass stops for 1/4" (6 mm) tempered glass (glass by others). Door is ready for custom fabrication to support additional hardware options for commercial storefront and entrance door applications.

Included protruding hardware (handles, pivots, etc.) ships boxed separately to prevent damage and must be installed by the customer. Note: door widths under 36" (914 mm) may not meet ADA inspection requirements.

Order SKU CD21911 or contact CRL for custom hardware options and lead times.
