CRL-U.S. Aluminum 36x84 KYNAR Paint Narrow Stile Butt-Hinge Door
CRL-U.S. Aluminum 36x84 KYNAR Paint Narrow Stile Butt-Hinge Door
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Item# CD21571
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Shipping Weight: NA
Shipping Limitations: None
Minimum Order Quantity: 1
Unit of Measure: each
Compliance and Restrictions
Warning: Reproductive Harm
www.p65warnings.ca.gov
Description
Finish/Color
Custom Kynar
Overview
- 9-1/2" (241 mm) bottom rail installed to comply with A.D.A.
- Custom fabricated to accept a wide range of optional hardware applications
- Includes standard push/pull, hanging hardware, MS hookbolt lock, and two keyed‑alike cylinders
- Accommodates 1/4" (6 mm) tempered glass (by others) with optional 1" (25 mm) tempered insulating unit available; glass not included
This CRL Custom Narrow Stile Entrance Door features 2" (51 mm) stiles, a 2-1/8" (54 mm) top rail and a 9-1/2" (241 mm) ADA-compliant bottom rail. Designed as a narrow-stile commercial entrance door, it ships ready for butt hinge hardware and glass stops for 1/4" (6 mm) tempered glass. Custom fabrication options make this door ideal for projects requiring specialized commercial hardware and tempered glass configurations.
Customer-installed protruding hardware (handles, pivots, etc.) is boxed separately to prevent transit damage. Note: door widths under 36" (914 mm) may not meet A.D.A. inspection requirements.
Order this customizable narrow stile commercial entrance door for ADA-compliant job sites — contact CRL for lead times and hardware options.
Specifications
BIM Objects - rvt
